The LRS-200-48 is a compact, high-efficiency AC/DC enclosed switching power supply from MEAN WELL, delivering a stable 48V DC output at up to 4.4A (211.2W). Its slim 30mm profile and robust design make it ideal for industrial and commercial applications where space and reliability are critical.
- Output Voltage: 48V DC (adjustable from 43.2V to 52.8V)
- Output Current: 4.4A
- Output Power: 211.2W
- Input Voltage Range: 90 ~ 132VAC / 180 ~ 264VAC (selectable), or 240 ~ 370VDC
- Efficiency: Up to 90%
- Ripple & Noise: ≤150mVp-p
- Protections: Short circuit, overload, over-voltage, over-temperature
- Cooling: Free air convection
- No-Load Power Consumption: <0.75W
- Operating Temperature: -25°C to +70°C (derating above 50°C)
- Dimensions: 215 × 115 × 30 mm
- Weight: Approximately 0.76 kg
- Warranty: 3 years
