TPM-01 ES Energy Analyzer with 4×4 Digit LED Display

Tense TPM-01 ES Three Phase Digital Energy Analyzer

The Tense TPM-01 ES is an industrial grade, panel mounted digital energy analyzer designed to measure, monitor, and record comprehensive electrical parameters across complex three phase power networks. Outfitted with an expansive, high visibility 4×4 digit LED display matrix, this advanced multimeter provides real time tracking of load variations, grid voltages, line currents, power factors, and consumption variables. Equipped with built in RS485 Modbus RTU communication protocols, the TPM-01 ES acts as an intelligent data terminal, seamlessly transmitting system harmonics and energy metrics to central PLCs or building management networks.

Key Features

High Density 4x4 Digit Display: Designed with a specialized four row, four digit red LED grid that displays simultaneous multi phase values, eliminating the need to manually cycle through screens to view primary line data.
Advanced Harmonic Tracking: Measures and analyzes total voltage and current harmonic distortion (THD-V / THD-I) up to the 31st harmonic, allowing engineers to identify dirty power signatures and protect sensitive components.
Complete Power and Factor Analysis: Tracks per phase metrics including active power ( $P$ ), reactive power ( $Q$ , inductive/capacitive), apparent power ( $S$ ), $cosvarphi$ and true system power factors ( $PF$ ).
Integrated RS485 Modbus Communication: Built with remote communication capabilities using the RS485 interface, facilitating automatic telemetry logging and remote performance reporting.
Comprehensive Parameter Logging: Automatically registers minimum, maximum, average, and peak demand metrics while tracking totalized active import/export energy ( $sum kWh$ ) and reactive energy arrays ( $sum kVArh$ ).

Technical Specifications

Feature	Specification
Model / Series	TPM-01 ES
Brand / Manufacturer	Tense Electronics
Display Configuration	4 Rows*4 Digit High Contrast Red LED matrix
Network Interface	3 Phase 4 Wire ( $3P4W$ ) or 3 Phase 3 Wire ( $3P3W$ ) networks
Harmonics Capability	Up to the 31st Harmonic ( $THD-V$ and $THD-I$ )
Communication Protocol	RS485 Modbus RTU Serial Interface
Auxiliary Output	1 Programmable Adjusting Relay Output
Security Architecture	Password Protected Configuration Menu
Application Segment	Automation Parts / Electrical Protection, Control, & Monitoring

Applications

Industrial Plant Substations: Monitoring large three phase transformer lines to maintain phase equilibrium and assess power usage efficiency.
Automation Control Enclosures: Placed inside primary panel doors next to variable frequency drives (VFDs) and heavy motor circuits to monitor and flag dangerous current harmonics.
Commercial Building Sub Metering: Integrating into energy management networks to compile accurate import/export electricity audits for billing.
Power Quality Diagnostic Control: Serving as an early warning alarm terminal using its internal relay output to trigger warning lights or disconnects if dangerous spikes occur.
