QUINT POWER SUPPLY 2866679 PHOENIX CONTACT

QUINT POWER SUPPLY 2866679 PHOENIX CONTACT

ر.ق 0.00

MEANWELL POWER SUPPLY

  1. Input Voltage Range: 85 V AC to 264 V AC / 90 V DC to 300 V DC
  2. Output Voltage: 48 V DC ±1%
  3. Output Current: 5 A
  4. Output Power: 240 W
  5. Efficiency: Up to 92.5%
  6. Dynamic Power Boost: Provides up to 6 A for short durations to start heavy loads
  7. SFB Technology: Delivers up to 30 A for 12 ms to selectively trip standard circuit breakers
  8. Operating Temperature: -25°C to +70°C (with derating above 60°C)
  9. Dimensions (W x H x D): 60 mm x 130 mm x 125 mm
  10. Protection Class: IP20
  11. Mounting: DIN rail
  12. Certifications: CE, UL Listed, cULus Recognized, EAC, DNV GL, ABS, BV, LR, NK



Category: Brand:

The Phoenix Contact QUINT-PS/1AC/48DC/5 is a high-performance DIN rail-mounted power supply designed for demanding industrial applications. Delivering a stable 48 V DC output at up to 5 A, this 240 W power supply ensures reliable performance in control cabinets and automation systems. Its advanced features, including Selective Fuse Breaking (SFB) technology and dynamic power boost, make it an ideal choice for systems requiring high reliability and availability.

  • Overvoltage Protection (OVP): Safeguards against voltage spikes.
  • Overcurrent Protection (OCP): Prevents damage from excessive current.
  • Short-Circuit Protection (SCP): Ensures safe operation during faults.
  • Overtemperature Protection (OTP): Protects against overheating.
  • Selective Fuse Breaking (SFB): Enables fast tripping of standard circuit breakers to isolate faulty circuits.
