A versatile tester designed for measuring AC/DC voltage, continuity, phase rotation, and RCD functionality, suitable for professional electricians and DIY users.
- Measures AC/DC voltage from 12V to 690V, including 3-phase systems
- Detects phase rotation in 3-phase AC systems
- Continuity testing with audible and visual indicators
- Tests Residual Current Devices (RCD) for safety verification
- Single-lead voltage detection capability
- Polarity indication (positive/negative)
- Self-check feature for LEDs and LCD
- Overvoltage warning for voltages exceeding safe limits
- Auto standby mode to save battery
- Silent mode to disable sound alerts
- Built-in LED work light for use in dark environments
- Low battery indication
Specifications:
- Voltage range: 12V to 690V AC/DC
- Frequency range: 50Hz to 400Hz
- Continuity test range: 0Ω to 100kΩ
- Operating voltage for RCD test: 230V
- Display: LCD with clear readings
- Ingress protection rating: IP65 (dust-tight and water-resistant)
- Safety rating: CAT IV 600V
- Power supply: 2 x AAA batteries
- Dimensions: Approx. 272mm × 85mm × 31mm
- Weight: Around 280g
